$1,599.00
* Ultra AL32 Processing
* DAC master clock
* HEOS® Built-in
* Alexa, Google, Siri voice control
* Quad DAC configuration
* AirPlay 2
Add streaming to any system
Perfectly complement any existing audio system by adding a premium digital hub for audio sources and music streaming with HEOS® Built-in for universal playback of digital music files.
Rich connectivity
High-quality audio from your digital and streaming sources.
Faithful audio reproduction
Ultra AL32 Processing delivers the richly detailed sound the artist intended.
Connect directly to your TV
Simple one-cable connection with any compatible HDMI ARC television.
Built-in streaming
HEOS® Built-in provides access to music streaming services and Airplay 2.
HDMI ARC
Simple, single-cable connection to your TV via HDMI ARC input. Also allows direct volume control from the television or amplifier remote.
Ultra AL32 Processing
Experience audio beautifully faithful to the original sound. Ultra AL32 Processing algorithms restore information that was lost during digital recording.
Quad DAC configuration
Using a quad DAC configuration enables an improved, more powerful spatial expression of the soundstage, decreasing the low noise level and total harmonic distortion.
USB-DAC
USB-DAC input allows connection to a computer to access high-resolution audio files, supporting hi-res up to 11.2-MHz DSD and 384-kHz/32-bit PCM input signals.
High-grade audio components
All audio components have been carefully selected and optimized for the best sound quality.
Isolation system
DNP-200NE’s analog and digital circuit boards are isolated from each other. An independent power line from the transformer protects the analog circuit from interference and noise.
Tailor your sound with complete connectivity & control. Every element of a Denon product is thoughtfully crafted to deliver an unforgettable audio experience.
Technical Information
Dimensions and weight:
4 1/4″ high x 17 1/16″ wide x 16 9/16″ deep
21 1/2 lbs.
General
Panel Color options: Silver/Black/Gray
Front (Center) Panel: Aluminum
Side Cover/Top Cover: Steel (SECC) t1.0mm
Bottom Layer/Bottom Plate: Double
Volume Rotary Knob: Aluminum
Function Button: Aluminum
Cursor/Enter/Function: Aluminum
Power Button: Aluminum
Audio (Lineout)
Frequency Response: DSD: 2 Hz–50 kHz (-3dB), PCM(44.1 kHz): 2 Hz–20 kHz
Harmonic Distortion: DSD: 0.0006%, PCM: 0.0008% (24 bit)
S/N: DSD: 120dB PCM: 118dB
Dynamic Range: DSD: 112dB, PCM: 118dB
Line Output Level: 2.2Vrms
Variable Output Level: 4.5Vrm
Headphone Output Level: 150mW/32 ohms high gain
Power Consumption
Power Consumption: 38W
at Standby: 0.2W
at Network Control On (all of Bluetooth, Ethernet, Wi-Fi, USB): Less than 2W
Analog Audio
Output Circuit: Minimum signal path
Power Transformer: EI transformer
H/P Amp Gain Setting: Yes (Low/Mid/High)
Digital Audio
DAC Circuit: 384 kHz/32 bit (ES9018K2M) x4
Digital Filter: Fixed
Digital Processing: ULTRA AL32 Processing
Jitter Reducer: Yes
DAC Master Clock Design: Yes (Does not support network playback)
Asynchronous Mode (for USB B input): yes
Isolator (for USB B input): Yes (and digital inputs)
Function
HEOS Control on Front Panel: Yes
HEOS Favorites Call/Add: Yes
Setup on Front Panel: Yes
Setup Assistant: Yes
TV Auto-Play (opt/coax digital-in detector): Yes
Last Function Memory: Yes
Volume Limit: Yes
Sleep Timer: Yes
Auto Standby Mode: Yes
KPI (for usage data): Yes
Accessories
Quick Start Guide: Yes
Remote Control: Yes
Battery: Yes (AAA x2)
Power Cord: Yes
Stereo RCA cable: x 1
IR control cable : x 1
| Weight | 26.5 lbs |
|---|---|
| Dimensions | 20.5 × 21.6 × 8.3 in |
| Color Choice |
Black ,Silver |
