PSB Alpha T20 Tower Floorstanding Speakers (Pair) – PSB

The PSB T20 Tower delivers the highest quality acoustics in the new Alpha Series and will easily fill any size room with lush, full-bodied sound. Leveraging the latest research in acoustic design and most advanced cabinet and driver technologies, the all-new Alpha tower adds an additional custom 5.25” woofer, while utilizing the Alpha Series’ patent tweeter and crossover design, to deliver bigger and bolder sound with flawless imaging.

Featuring PSB’s exclusive dual 5.25” woofer connected to a dual-layer voice coil for incredible conductivity, the newest Alpha Series tower provides remarkable low-frequency response and the exceptional efficiency for a speaker at this price. Starting with a specially textured polypropylene cone that lowers distortion and reduces breakup, the woofer is perfectly matched with the tweeter at the crossover for a smooth sounding transition between high and low frequencies. It’s also backed with a rear-firing port that uses bass flex to tightly control the bass response and extend it even lower.

Using a special MDF material and a unique combination of wall thickness and bracing, the Alpha T20 Tower flawlessly controls resonances while leveraging a light internal material that has been accurately positioned to reduce standing waves.

Features:

• .75” Black anodized aluminum dome tweeter with front waveguide
• Two 5.25” Textured polypropylene woofers with rubber surround
• Bass reflex cabinet design with a rear-firing port
• Acoustically-transparent detachable magnetic grilles
• Dual five-way gold-plated binding post speaker terminals
• High-quality woodgrain vinyl finish
• Available in Black Ash or American Walnut
• Specs
• Frequency Response
• On Axis @ 0° ± 3dB: 36-21,000Hz
• On Axis @ 0°±1 1/2dB: 54-20,000Hz
• Off Axis @ 30°±3dB: 54-10,000Hz
• LF Cutoff -10dB: 28Hz
• Sensitivity
• Anechoic Chamber: 88dB
• Typical Listening Room: 90dB
• Impedance
• Nominal: 8 Ohms
• Minimum: 6 Ohms
• Input Power
• Recommended: 15-120 Watts
• Program: 60 Watts
• Acoustic Design
• Tweeter (Nominal): 3/4” (19mm) Black Anodized Aluminum Dome with Ferrofluid and Neodymium Magnet
• Woofer (Nominal): 2 x 5 1/4” (133mm) Textured Polypropylene Cone with Rubber Surround
• Crossover: 2,500Hz, L4
• Design Type: Tuned Port Bass Reflex 2 1/2” (63.5mm) Rear Port
• Construction
• Cabinet Sleeve: 5/8” (15mm) MDF
• Baffle Front: 1” (25.4mm) MDF
• Baffle Rear: 5/8” (15mm) MDF
• Grille Face: Black Steel Micro Perf with
• Frame: Magnetic Attachment
• Size (W x H x D)
• Net: 6 3/4” x 32 1/2” x 9 3/8” * (170 x 825 x 243mm)
• Weight
• Net: 26.15lb (11.9kg)/each
• Shipping: 62.7lb (28.5kg)/pr
• Finish
• Black Ash or Walnut in Vinyl Clad
